Product Summary
The TCD1703C is a high sensitive and low dark current 7500 elements CCD image sensor. The sensor is designed for facsimile, imagescanner and OCR. The TCD1703C contains a row of 7500 elements photodiodes which provide a 24 lines/mm across a A3 size paper. The device is operated by 5V, and 12V power supply.
Parametrics
TCD1703C absolute maximum ratings: (1)clock pulse volage, VΦ: -0.3 to 8V; (2)shift pulse voltage, VSH: -0.3 to 8V; (3)reset pulse votlage, VRS: -0.3 to 8V; (4)clamp pulse voltage, VCP: -0.3 to 8V; (5)power supply voltage, VOD: -25 to 60℃; (6)storage temperature, Tstg: -40 to 100℃.
Features
TCD1703C features: (1)number of image sensing elements: 7500 elements; (2)image sensing element size: 7um by 7um on 7um centers; (3)photo sensing region: high sensitive and low voltage dard signal pn photodiode; (4)clock: 2 phase (5V); (5)package: 22 pin DIP.
