AD590JH

Two-Terminal IC Temperature Transducer, 1 μA/K, 30v, SSOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $3.12~4.65 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $3.12~4.65

PartNumber:: AD590JH

Brand:: Analog Devices - ADI | Pack: CAN | D/C: 05+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Becky's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2012-07-14

From Other Seller

Part Number:AD590JH
US $3.12 - 4.65
EKY-160ELL121MF11D

US $0.10 - 1.00 / Piece
(0) Remove
ECA1HHG220

US $2.00 - 10.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AD590JH is a 2-terminal integrated circuit temperaturetransducer that produces an output current proportional toabsolute temperature. For supply voltages between 4 V and 30 Vthe device acts as a high-impedance, constant current regulatorpassing 1 μA/K. Laser trimming of the chip’s thin-film resistorsis used to calibrate the device to 298.2 μA output at 298.2 K(25℃). In addition to temperature measurement, applications includetemperature compensation or correction of discretecomponents, biasing proportional to absolute temperature, flowrate measurement, level detection of fluids and anemometry. The AD590JH is available in chip form, making it suitable forhybrid circuits and fast temperature measurements in protectedenvironments.

Parametrics

AD590JH absolute maximum ratings: (1)Forward Voltage: 44V; (2)Reverse Voltage: -20V; (3)Breakdown Voltage: ±200V; (4)Rated Performance Temperature Range: -55℃ to +150℃; (5)Storage Temperature Range1: -65℃ to +155℃; (6)Lead Temperature (Soldering, 10 sec): 300℃.

Features

AD590JH features: (1)Linear current output: 1 μA/K; (2)Wide temperature range: -55℃ to +150℃; (3)Probe compatible ceramic sensor package; (4)2-terminal device: voltage in/current out; (5)Laser trimmed to ±0.5℃ calibration accuracy (AD590M); (6)Excellent linearity: ±0.3℃ over full range (AD590M); (7)Wide power supply range: 4 V to 30 V; (8)Sensor isolation from case; (9)Low cost.
