Product Summary

The S5B26 is a 5.0A surface mount glass passivated rectifier.

Parametrics

S5B26 maximum ratings and electrical characteristics: (1)Peak Repetitive Reverse Voltage, VRRM: 100v; (2)Working Peak Reverse Voltage, VRWM: 100v; (3)DC Blocking Voltage, VR: 100v; (4)RMS Reverse Voltage, VR(RMS): 70V; (5)Average Rectified Output Current @ TT = 75℃, IO: 5.0 A; (6)Non-Repetitive Peak Forward Surge Current, 8.3ms single half sine-wave superimposed on rated load(JEDEC Method), IFSM: 100 A; (7)Forward Voltage @ IF = 5.0A, VFM: 1.15 V; (8)Peak Reverse Current, IRM: 10 uA @TA = 25℃; 250 uA at Rated DC Blocking Voltage @TA = 125℃; (9)Typical Total Capacitance, CT: 40 pF; (10)Typical Thermal Resistance, Junction to Terminal, RθJT: 10 ℃/W; (11)Operating and Storage Temperature Range, Tj, TSTG: -65 to +150 ℃.

Features

S5B26 features: (1)Glass Passivated Die Construction; (2)Low Forward Voltage Drop and High Current Capability; (3)Surge Overload Rating to 100A Peak; (4)Ideally Suited for Automated Assembly.

Diagrams

S5B26 dimension
