Product Summary

The D65632GF112 is a CMOS-6 gate array. It is an ultra-high perfroamnce, sub-micron effective channel length CMOS product created for high-intefration ASIC applicatiosn.

Parametrics

D65632GF112 absolute maximum ratings: (1)power supply voltage, VDD: -0.5 to 6.5V; (2)input/output voltage, VI/VO: -0.5 to VDD+0.5V; (3)latch-up current, ILATCH: >1A typ; (4)operating temperature, Topt: -40 to 85℃; (5)storage temperature, Tstg: -65 to 150℃.

Features

D65632GF112 features: (1)channelless, 1um CMOS high-density architecture; (2)variable output drive; (3)slew rate output buffers; (4)free size memory block to 64Kbytes; (5)powerful block library with more than 400 macros; (6)3V characterized block library; (7)new 0.65mm 184-pin plastic QFP for cost effective designs.

Diagrams

D65632GF112 block diagram
