Product Summary

The 11-22SURSYGC-S530-A2-TR8 is a Chip LED with Bi-Color(Multi-Color). The 11-22SURSYGC-S530-A2-TR8 SMD Taping is much smaller than lead frame type components, thus enable smaller board size, higher packing density, reduced storage space and finally smaller equipment to be obtained. Besides, lightweight makes them ideal for miniature applications. etc. The applications of the 11-22SURSYGC-S530-A2-TR8 are (1)Automotive: backlighting in dashboard and switch; (2)Telecommunication: indicator and backlighting in telephone and fax; (3)Flat backlight for LCD, switch and symbol; (4)General use.

Parametrics

11-22SURSYGC-S530-A2-TR8 absolute maximum ratings: (1)Reverse Voltage VR: 5 V; (2)Forward Current IF:25 mA; (3)Operating Temperature Topr: -40 ~ +85℃; (4)Storage Temperature Tstg: -40~ +90℃; (5)Soldering Temperature Tsol: 260℃ (for 5 second); (6)Electrostatic Discharge (HBM) ESD: 2000 V; (7)Power Dissipation Pd:60 mW; (8)Peak Forward Current(Duty 1/10 @1KHz), IFP: 60 mA; (9)Soldering Temperature Tsol: 260 ℃ for 10 sec.

Features

11-22SURSYGC-S530-A2-TR8 features: (1)Package in 8mm tape on 7" diameter reel; (2)Compatible with automatic placement equipment; (3)Compatible with infrared and vapor phase reflow solder process; (4)Mulit-color type; (5)Pb-free; (6)The product itself will remain within RoHS compliant version.

Diagrams

11-22SURSYGC-S530-A2-TR8 block diagram
