Product Summary
RFL6000 device is a low noise amplifier. Operating modes — Sleep, Rx and Rx/Tx — as well as LNA bias currents, are all automatically adjusted via software to minimize DC power consumption. Depending on handset status, the LNA bias current adjusts automatically to meet RF performance requirements with minimal power consumption. The device is fabricated using a SiGe BiCMOS process, which is suited for high performance RF circuits. The RFL6000 device is packaged in a very small 16-pin bump chip carrier (16-pin BCC++).
Features
RFL-6000 features: (1)radioOne chipset eliminates receiver and transmitter IF, reducing component count, space and cost; (2)Programmable mode control to reduce DC power consumption; (3)High-reverse isolation; (4)Efficient three-line serial bus interface (SBI); (5)Low power consumption; (6)Fabricated in SiGe BiCMOS process; (7)Small package: 16-pin BCC++ (4 mm x 4 mm).
