Product Summary

The MAX5309EUE is a 10-bit, eight channel, low-power, voltage-output, digital-to-analog converter (DAC) in a spacesaving 16-pin TSSOP package. The wide +2.7V to +5.5V supply voltage range and less than 215µA (max) supply current per DAC is excellent for low-power and low-voltage applications. The low 2nV-s glitch energy of the MAX5309EUE makes it ideal for digital control of fast-response, closed-loop systems. The MAX5309EUE has a hardware reset input (CLR-bar) which clears all registers and DACs to zero. The MAX5309EUE has a software shutdown feature that reduces the supply current to 1µA. The MAX5308 features a load DAC (LDAC-bar) function that updates the output of all eight DACs simultaneously.

Features

MAX5309EUE features: (1)VDD to GND: -0.3V to +6V; (2)All Other Pins to GND: -0.3V to (VDD + 0.3V); (3)Maximum Current Into Any Pin: ±50mA; (4)Operating Temperature Range: -40℃ to +85℃; (5)Junction Temperature: +150℃; (6)Storage Temperature Range: -65℃ to +150℃; (7)Lead Temperature (soldering, 10s): +300℃.

Diagrams

MAX5309EUE circuit
