Product Summary

The FLI8548H-LF-BE is a single-chip enhanced LCD TV controller with HDMI. The FLI8548H-LF-BE offers high integration for advanced applications of Picture-in-Picture (PIP) and Picture-by-Picture (PBP) with an integrated video decoder, a 3D comb filter, and an HDMI receiver. Additionally, the FLI8548H can power up to 1080p displays with the proven DCDi Cinema technology. The FLI8548H-LF-BE can also be used as part of a digital TV solution that requires the proven Faroudja DCDi Cinema video performance. Applications include LCD and PDP TV and LCD, and LCOS front and rear projection.

Features

FLI8548H-LF-BE features: (1)Integrated HDMI input; (2)Integrated 3D video decoder; (3)Flexible digital and analog capture up to 150 MHz ; (4)VBI signal processing including WST version 2.5 support; (5)Flexible DDR memory interface; (6)Advanced Picture-in-Picture (PIP) features; (7)Advanced Color Management (ACM-3D) and Adaptive Contrast Control (ACC); (8)On-chip microprocessor; (9)Advanced bitmapped OSD controller ; (10)LCD overdrive; (11)Embedded 10-bit dual-channel LVDS for 1080p and WUXGA panel support.

Diagrams

FLI8548H-LF-BE System diagram
